Outdoor Electric Hoist Operated Industrial Gantry Crane with Cantilever Beam for Storage Yard
Nucleon (Xinxiang) Crane Co., Ltd.- After-sales Service：Technical Advisory of Installation & Commissioning
- Warranty：12 Month Warranty After Successful Installation
- Certification：CE, ISO9001, ISO14001
- Condition：New
- Maximum Lifting Weight：<20t
- Maximum Lifting Height：15-20m
Base Info
- Model NO.：MH
- Operation Form：Air Operation+Ground Operation
- Type：Rail Mounted Gantry Crane
- Main Girder Form：Single Girder
- Load Capacity：up to 20 Ton
- Span：up to 30 Meters
- Height of Lift：up to 18 Meters
- Control：Radio Remote,Operation Cabin,Pendant Control
- Power Supply：380~480V, 50~60Hz, 3phase
- Hoisting Speed：0.8~5 M,Min (VFD)
- Hoist Travel Speed：2~20 M,Min (VFD)
- Crane Travel Speed：4~40 M,Min (VFD)
- Duty Class：A5 (ISO)
- Permitted Wind Speed：Less Than 12 M,S (Outdoor)
- Cantilever：Available at Either or Both Gantry Side
- Lead Time：Within 30 Days
- Installation：Video Tutorial, Site Installation & Commissioning
- Random Files：Operation & Maintenance Manual, Wiring Diagram
- Spare Parts：Provide Random Spares for Two Year Maintenance
- Transport Package：Wooden Case, Waterproof Film
- Specification：Single hoist,Tandem Control with Two Hoists
- Trademark：Nucleon Crane
- Origin：Henan, China
- HS Code：8426112000
- Production Capacity：600 Sets Per Annum
