China Mobile Truck Crane 25t
Uptra Electric & Machinery (Shanghai) Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>16t
- Shaft Number：3
- Crane Jib：Five-Arm
Base Info
- Model NO.：hydraulic truck crane
- Type：Folding
- Overall Dimension：12650X2500X3380mm
- Wheel Base：4425+1350mm
- Track：2074,1834,1834mm
- Max. Travel Speed：75km,H
- Min. Travel Speed：2.9km,H
- Min. Turning Diameter：22m
- Min. Ground Clearance：260mm
- Max. Grade Ability：30%
- Application：Construction Lifting
- Engine Rated Power：206,2200kw,(R,Min)
- Engine Rated Torque：1112,1400n.M,(R,Min)
- Approach Angle：16degree
- Departure Angle：13degree
- Braking Distance：Less Than10m
- Max. Total Rated Lifting Capacity：25t
- Transport Package：Nacked
- Specification：CE
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：8705109100
- Production Capacity：10000PCS,Year
Description
Max. load momentBase boomKN.m1000Fully-extended boom 600Fully-extended boom + Jib 376Outrigger spanLongitudinalm5.14Lateral 6Hoist heightBase boomm10.8Fully-extended boom 34.19Fully-extended boom + Jib 42.3
