Cost-Effective Special Crane Load Moment Indicator 7inch Touch Screen

Hubei Ronghui Intelligent Electric Co., Ltd.
  • After-sales Service：The Surrounding Auxiliary Parts
  • Condition：New
  • Warranty：2 Years
  • Transport Package：Standard Export Cartons
  • Specification：222MM*145MM*80MM
  • Trademark：NE

Base Info

  • Model NO.：C-C001.1
  • Origin：China
  • HS Code：8431499900
  • Production Capacity：2000

Description

Basic Info.

Model NO. C-C001.1 Origin China HS Code 8431499900 Production Capacity 2000

Product Description

Load moment indicator is a device installed in all kinds of cranes, such as mobile, caterpillar, tower, gantry, gantry, Marine and offshore crane. If beyond the scope of safe operation, it will remind the operator.
Cost-Effective Special Crane Load Moment Indicator 7inch Touch Screen



Model: C - C001
Display: 1024 * 600 7 inches of liquid crystal
Working temperature: - 20 ºC ~ 70 ºC
Working humidity: 95% RH (25 ºC)
Weighing measuring range: 0 T ~ 999.9 T
Resolution: 0.1 T
Signal input: < = 6 channels
Control output: < = 6 channel + RS485 + remote wireless monitor
System error: plus or minus 5% (FS)
Power consumption: < 30 w
Alarm volume: > 60 db
IP protection grade: 65
Power supply: DC24V
