• Model NO.：SRC750
• Shaft Number：3
• Crane Jib：Four-Arm
• Type：Folding
• Max. Lifting Height：108m
• Rated Loading Capacity：180ton
• Rated Lifting Moment：8050 Kn.M
• Span：360
• Output Power：420kw
• Overall Weight：44900kg
• Transport Package：Nude Package
• Specification：75 ton
• Trademark：S ANY
• Origin：Hunan, China
• Production Capacity：100pieces,Month

Basic Info.

Model NO. SRC750 Shaft Number 3 Crane Jib Four-Arm Type Folding Max. Lifting Height 108m Rated Loading Capacity 180ton Rated Lifting Moment 8050 Kn.M Span 360 Output Power 420kw Overall Weight 44900kg Transport Package Nude Package Specification 75 ton Trademark S ANY Origin Hunan, China Production Capacity 100pieces/Month

Product Description

S A N Y SRC750, 75 tons Rough Terrain Crane



*********************************************************************************************************************************

Excellent traveling performance

Two-axle off-road chassis with max.travelling speed of 37 km/h and max.gradeability of 75%;

Four-wheel steering control system and dual-circuit braking system provide the RT crane with flexible and safe operation.

Energy-saving hydraulic system

Load sensitivity control and constant-power control system: achieving proportional speed adjustment and power adaption adjustment with no throttling loss and good energy-saving effect.

Safety devices

Load moment limiter can provide comprehensive protection for the lifting operation and will alarm if the crane is overloaded, guaranteeing operation safety.

A three-wrap rope protector is applied to both main and auxiliary winches to prevent over rolling-out of wire rope

A height limiter is applied at both boom and jib ends to prevent over-hoisting of the wire rope.


Item	Specification	Unit
Overall Length	14248	mm
Overall Width	3340	mm
Overall Height	3800	mm
Wheel Base	2562	mm
Total vehicle mass in travel configuration	53440	kg
Axle Load	27600+25840	kg
Engine Model	---
Engine rated power	210/2500	kw/rpm
Engine rated torque	970/1500	N.m/rpm
Max. travel speed	40	km/h
Min. turning diameter	12.5/7.5	m
Max. gradeability	75	%
Min. ground clearance	350	mm
Approach angle	20	°
Departure angle	19	°
