• Model NO.：QL
• Driving Type：LHD,Rhd
• Engine Model：4kh1-Tcg40
• Engine Displacement：2.999L
• Application：Construction Usage
• Tower Crane Type：Slewing Tower Crane
• Sling Type：Cable
• Main Girder Form：Double Girder
• Power Source：Hydraulic
• Transport Package：Nude
• Specification：6170x2120x3280 mm
• Trademark：Isuzu
• Origin：China
• Production Capacity：800 Units,Month

Model No.SGZAxles2G.V.W(Kg)6810Emission StandardEuro IVCurb weight(Kg)4000Overall dimension (mm)6170x2120x3280Rated weight(Kg)2485Axles Load(Kg)2090/4720Passengers allowed2 or 3Front/rear suspension (mm)1015/1880Approach/departure angle (°)24/12Front/rear Tread(mm)1504/1425Wheelbase(mm)3815Max speed(Km/h)105Leaf of springs8/6+5Tire 7.00-16 14RP,7.00R16 14RPEngine Model4KH1-TCG40Emission(ML)/ power(Kw)2999/88Crane specifications arm-type SQS68, folding arm SQZ68, weight 1100kg, lifting load 3200kg. Protective Material: Q235A carbon steel connections: left and right side and rear underrun protection are made of welded connections, the rear protective section size (mm): 140x30, rear protective ground clearance (mm): 500. With the optional chassis cab, optional narrow front bumper.
Our Advantage
1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as a manufacturer
3.Products Quality Certification SGS CCC ISO
4.Perfect after-sale service
5.Customized products available with us
6.Export to more than 50 countries and regions
7.Oversea wareshouse with more than 100000 US dollors spare parts in stock
8.Oversea office with more than 15 professional engineers to help local customers

Main products
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )

FAQ
1. MOQ: 1 unit
2. Optional payment terms: T/T or L/C
    T/T: 30% deposit by T/T, 70% balance should be paid before shippment.
    L/C: 30% payment advance, 70% L/C at sight.
3. Parts of famous brand can be adopted by your requirement, such as WABCO, JOST, BPW, FUWA.
4. Delivery time: Within15 workdays after receiving 30% deposit of T/T

Warranty
1. Six months quality guarantee for three key parts axles, engine, transmission or within 50000km, which comes first.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.

About us
SINOTRUK is the leader in Chinese truck industry, founded in 1956, successively cooperated with Many Europe top manufacturers like Styre,Volvo and MAN. In 2007,we listed in the red-chip Hong Kong ,Germany MAN is our sencond largest share holder. Through centuries development, we have owned 20 subsidiaries in China, our products exported all around the world.



Your are always welcome to visit our factory at any time.

Rita Du

SINOTRUK Hubei Huawin Special Vehicle Co.,Ltd
