XCMG Official Qy70K-I 70ton China Famous Hydraulic Mobile Truck Crane
Xuzhou Construction Machinery Group Import & Export Co., Ltd.- Certification：GS, CE, ISO9001:2000
- Condition：New
- Maximum Lifting Height：44.5m
- Maximum Lifting Weight：70ton
- Type：Truck Crane
- Engine Rated Power：276,2200kw,(R,Min)
Base Info
- Model NO.：QY70K-I
- Engine Rated Torque：1500,1400n.M,(R,Min)
- Max. Travel Speed：80km,H
- Min. Steady Travel Speed：3km,H
- Min. Turning Diameter：24m
- Min. Turning Diameter at Boom Tip：39m
- Total Mass Under Driving Status：48000kg
- Span：6.1m
- Transport Package：Comply with Export Packaging Requirment
- Specification：13900*2800*3575mm
- Trademark：XCMG
- Origin：Xuzhou, Jiangsu, China
- HS Code：87059091
- Production Capacity：10000,Year
Description
DescriptionUnit Parameter value Overall length mm 13900 Overall width mm 2800 Overall Height mm 3575 Axle base 1st ,2nd axle mm 1470 2nd ,3rd axle 4105 3rd ,4th axle 1350 Wheel Base mm 2304+2075 Total vehicle mass in travel configuration kg 43000 (not including auxiliary counterweight of 1t) Axle load 1st and 2nd Axle kg 17000 3rd and 4th Axle 26000 Engine Model WD615.338 Engine rated power kw/(r/min) 276/2200 Engine rated torque N.m/(r/min) 1500/1400 Engine rated rotational speed r/min 2100 Max. travel speed km/h 80 Min. steady travel speed km/h 3 Min. turning diameter m 24 Min. turning diameter at boom tip m 29 Min. ground clearance mm 327 Max. grade ability % 40 Approach angle ° 19 Departure angle ° 11 Braking distance (at 30 km/h, full load ) m ≤10 Oil consumption per 100km L 45
[Product Picture]
[Company Information]
[FAQ]
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted.
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC.
3: What about the delivery time?
A: 7-30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
