• Model NO.：hydraulic truck crane
• Type：Folding
• Overall Dimensio：12650X2500X3380mm
• Wheel Base：5025+1350mm
• Track：2074,1834,1834mm
• Max. Travel Speed：80km,H
• Min. Travel Speed：3km,H
• Min. Turning Diameter：22m
• Min. Ground Clearance：291mm
• Max. Grade Ability：40%
• Application：Construction Lifting
• Engine Rated Power：206,2200kw,(R,Min)
• Engine Rated Torque：1112,1400n.M,(R,Min)
• Approach Angle：19degree
• Departure Angle：13degree
• Braking Distance：Less Than10m
• Max. Total Rated Lifting Capacity：50t
• Transport Package：Nacked
• Specification：CE
• Trademark：Super-above
• Origin：China
• HS Code：8705109100
• Production Capacity：10000PCS,Year

Max. load momentBase boomKN.m2009Fully-extended boomKN.m1129Boom lengthBase boomm11.4Fully-extended boomm43.5Fully-extended boom + Jibm59.5Max. total rated lifting capacity t50Min. rated working radius m3Turning radius at turntable tail mm3800Max. load momentBase boomKN.m2009Fully-extended boomKN.m1129Outrigger spanLongitudinalm6.1Lateralm7.1Hoist heightBase boomm11.9Fully-extended boomm44Fully-extended boom + Jibm58.1Boom lengthBase boomm11.4Fully-extended boomm43.5Fully-extended boom + Jibm59.5Engine Model WD615.338 Engine rated powerkw/(r/min)276/2200 Engine rated torqueN.m/(r/min)1500/1300-1600 Max. travel speedkm/h85
