Item | Unit | Value | Remarks |
---|
Working performance | Max. rated lifting capacity | kg | 150000 | At 3m radius |
Max. load moment of basic boom | kN.m | 4704 | At 6m radius |
Max. load moment of max. length boom boom(fully extended) | kN.m | 1505 | At 32m radius |
Max. load moment of basic boom | m | 13.0 | |
Max. lifting height of main boom | m | 72 | These parameters do not include deflection of main boom and jib. The value in the brackets is the value with the extension installed. |
Max. lifting height of jib | m | 87/(95) |
Working speeds | Max. hoist rope speed(Main winch) | m/min | 114 | At the 4th layer |
Max. hoist rope speed(Auxiliary winch) | m/min | 74 | At the 3rd layer |
Boom derricking up time | s | 94 | |
Boom extendingt time | s | 860 | |
Max. Slewing speed | r/min | 1.4 | |
Driving parameters | Max. driving speed | km/h | 75 | |
Max. gradeability | % | 40 | |
Turning diameter | m | ≤20 | |
Min. ground clearance | mm | 305 | |
Limits for exhaust pollutants and smoke | | Conform to related standards | GB3847-2005/GB17691-2005(National Stage 4) |
Fuel consumption per hundred kilometers | L | 76 | |
Mass | Deadweight in driving condition | kg | 60000 | |
Complete vehicle kerb mass | kg | 59805 | |
Load on axles 1,2 and 3 | kg | 12000 | |
Load on axles 4 and 5 | kg | 12000 | |
Dimensions | Overall dimensions(L×W×H) | mm | 15390×3000×4000 | |
Outrigger spread(L) | m | 8.43 | |
Outrigger spread(W) | m | Fully extended:7.8, Intermediately extended:5.3 | |
Main boom length | m | 13.5 - 72 | |
Boom angle | ° | -0.5 - 82 | |
Jib length | m | 11,18.6 | |
Jib + extension length | m | 26.6 | |
Offset | ° | 0,30 | |
