• Model NO.：ZTC1100
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Folding
• Transport Package：Nude, Spare Parts and Tools Into Standard Cases
• Specification：15000*2850*3820mm
• Trademark：Zoomlion
• Origin：China
• HS Code：87051091
• Production Capacity：5000PCS,Year

Item

Value

Remarks

Working performance

Max. rated lifting capacity     kg

110000

Max. load moment of basic boom                  kN.m

3540

Max. load moment of max. length main boom       kN.m

1728

Max. lifting height of basic boom                     m

13.7

Max. lifting height of main boom

m

59.2

These parameters do not   include deflection of main boom and jib.

Max. lifting height of jib        m

86.0

Working speeds

Max. hoist rope speed (Main winch)                m/min

≤130

Drum 4^th   layer

Max. hoist rope speed (Auxiliary winch)       m/min

≤110

Drum 2^nd   layer

Boom derricking up time     s

60

Boom telescoping out time     s

480

Slewing speed          r/min

0 - 1.6

Max. driving speed      km/h

90

Max. gradeability             %

40

Min. turning diameter       m

23

Min. ground clearance    mm

310

Oil consumption per hundred kilometer                 L

46

Mass

Deadweight in driving condition

kg

50000

Complete vehicle kerb mass

kg

49805

Front axle load              kg

24000

Rear axle load              kg

26000

Dimensions

Overall dimensions (L × W × H)

mm

15000×2850×3820

Outrigger spread (L)          m

6.38

Outrigger spread (W)         m

Fully extended: 8.0 m

Intermediately extended:   5.3 m

Tail slewing radius        mm

4420

Main boom length            m

12.5-58.5

Boom angle                  °

-2 - 80

Jib length                    m

10.4, 17.5

Jib offset                       °

0, 15, 30

Extension length              m

9.5

Optional

Extension offset               °

0

Tip boom length               m

3

Optional

Tip boom offset                °

30
